The Estate
Donald A. Hall Estate Collection
The Donald A. Hall Estate Collection contains the definitive, original 1927 engineering blueprints, technical notes, and historical photographic negatives documenting the design and construction of the Spirit of St. Louis (Ryan NYP).
Explore the Estate Collection
948 images from the family-held record. Search captions and descriptions, and open any image to view it in full.
948 images
A vintage flight-test photograph capturing the Ryan NYP Spirit of St. Louis in flight over Camp Kearny during the May 4, 1927 performance evaluations. Viewed from ground level as the monoplane banks gently against an overcast sky, the image records flight stability, control response, and climb angle measurements logged by Donald Hall to verify aerodynamic calculations prior to transatlantic flight clearance.
Donald A. Hall Estate Collection
An archival halftone documentary print recording the fuel calibration setup for the Spirit of St. Louis at Camp Kearny, San Diego. The aircraft rests on the unpaved field beside a stack of 55-gallon steel gasoline drums used by Ryan ground mechanics to pump measured fuel increments into the fuselage tanks. Donald Hall monitored each fueling stage to document takeoff distance versus gross weight across 70 to 300 gallons of gasoline.
Donald A. Hall Estate Collection
An archival factory engineering photograph showing the uncovered fuselage frame and cockpit interior of the Spirit of St. Louis inside the Ryan workshop. Mounted directly behind the curved aluminum bulkhead of the 425-gallon main fuel tank, the black oval instrument board displays the Pioneer magnetic compass, altimeter, airspeed indicator, engine tachometer, liquid column inclinometer, and throttle quadrant linkages within the welded chrome-molybdenum steel-tube truss.
Donald A. Hall Estate Collection
A primary construction negative documenting the uncovered welded steel-tube fuselage of the Spirit of St. Louis supported on wooden sawhorses inside the Ryan factory loft. The Wright J-5C Whirlwind radial engine is bolted to the front mounting ring, showing the open structural truss, main fuel tank installation, cockpit enclosure framing, and upper wing attachment joints prior to fabric covering.
Donald A. Hall Estate Collection
An archival flightline photograph detailing the left forward fuselage of the completed Spirit of St. Louis at Dutch Flats. The image details the hand-turned damascened nose cowl with "Spirit of St. Louis" lettering, the Wright radial engine cylinders, landing gear struts, fabric wheel cover, cockpit window, and the sliding external periscope housing aperture engineered by Donald Hall to provide forward visibility past the main fuel tank.
Donald A. Hall Estate Collection
An archival engineering flightline photograph detailing the left forward fuselage of the Ryan NYP Spirit of St. Louis at Dutch Flats, San Diego. The composition captures the hand-turned damascened nose cowl with painted script lettering, the Wright J-5C Whirlwind radial engine, landing gear struts with aerodynamic fairings, and the rectangular periscope aperture above the cockpit window. On the lower right edge of the frame beneath the fuselage, the legs and shoes of a Ryan crew member or bystander standing behind the plane are visible, recording the active flightline environment during pre-flight calibrations.
Donald A. Hall Estate Collection
A primary engineering photograph capturing a true head-on perspective of the Ryan NYP Spirit of St. Louis on the dirt runway at Dutch Flats. Photographed to confirm transverse symmetry, the image details the full 46-foot wingspan, the high-lift Clark Y airfoil profile, the engine-turned propeller spinner, and the 10-foot wide-track split-axle landing gear. Chief Engineer Donald A. Hall Sr. used these head-on alignment views to verify wing dihedral and rigging tension before flight clearing the aircraft.
Donald A. Hall Estate Collection
An archival flightline photograph capturing the Spirit of St. Louis from a low-angle front-left three-quarter perspective at Dutch Flats. The view highlights the long span of the high wing, the triangulated steel lift struts, the damascened nose cowl, and the streamlined landing gear fairings. Preserved in the Donald A. Hall Estate Collection, this negative documents the completed monoplane during engine run-ups and taxi evaluations prior to its transcontinental departure.
Donald A. Hall Estate Collection
A dramatic low-angle archival photograph taken near the port landing wheel of the Spirit of St. Louis looking up at the underside of the left wing. The composition prominently displays the large black painted registration letters "N-X-211" across the fabric-doped wing surface. The view also captures the Clark Y wing curvature, lift strut attachment points, the Wright Whirlwind engine, and the tail skid resting on the unpaved airfield.
Donald A. Hall Estate Collection
An archival flightline negative detailing the port underside of the Ryan NYP at Dutch Flats. The perspective frames the lower wing surface with bold registration lettering, the hand-turned damascened nose cowl, exhaust stacks, cockpit window, and landing gear wheels resting on the cracked mud apron. The image provides detailed photographic evidence of the aerodynamic and fabric finish executed by the Ryan Airlines shop under Donald Hall's supervision.
Donald A. Hall Estate Collection
An elevated perspective photograph taken from a raised platform or ladder looking down at the front-right quarter of the Spirit of St. Louis. The image captures the upper camber of the Clark Y wing, the right wing lift struts, the Wright radial engine, and the wide landing gear footprint. The long diagonal shadow cast across the unpaved airfield provides visual documentation of sun position and ground stance during pre-flight checks.
Donald A. Hall Estate Collection
An archival flightline photograph showing the complete left side of the Ryan NYP Spirit of St. Louis on Dutch Flats. The view details the balanced rudder stenciled with "N-X-211", the winged Ryan logo, "RYAN NYP", and "MFG. BY RYAN AIRLINES SAN DIEGO, CALIF.". In the background beyond the tidal flats, a column of smoke rises above the San Diego hills, framing the historic transatlantic aircraft in its operational setting.
Donald A. Hall Estate Collection
A high-angle archival photograph taken from above and behind the tail of the Spirit of St. Louis at Dutch Flats. The photograph clearly displays the massive black civil registration "N-X-211" painted across the upper surface of the right wing. Directly forward of the aft fuselage turtledeck, the rectangular cockpit skylight window is visible in the wing center section, engineered by Donald A. Hall to provide upward visibility and cockpit illumination.
Donald A. Hall Estate Collection
An archival flightline photograph documenting the starboard three-quarter profile of the completed Spirit of St. Louis at Dutch Flats. The view highlights the right side of the damascened aluminum nose cowl with "Spirit of St. Louis" lettering, the Wright Whirlwind engine, propeller, cockpit entrance door, and wing lift struts extending outward along the 46-foot wing.
Donald A. Hall Estate Collection
A comprehensive historical photograph recording the Ryan NYP Spirit of St. Louis from the left three-quarter angle on the dirt field at Dutch Flats. The image details the complete aircraft from the engine nose cone to the empennage, showing the landing gear track, fabric wheel discs, wing lift struts, and tail skid. The background displays the perimeter fences and hills of San Diego, documenting the final flight-testing phase prior to the historic flight.
Donald A. Hall Estate Collection
An archival engineering flightline photograph providing a detailed study of the forward nose assembly of the Ryan NYP Spirit of St. Louis at Dutch Flats, San Diego. The image details the hand-turned damascened aluminum nose cowl with dark script "Spirit of St. Louis" lettering, the Wright J-5C Whirlwind 9-cylinder radial engine with exposed rocker arms and pushrods, and the aerodynamic fairings on the forward landing gear struts. The damascened spinner and duralumin propeller blade are captured against the San Diego horizon, documenting the handcrafted metal finishing executed by the Ryan factory crew under Donald A. Hall's supervision.
Donald A. Hall Estate Collection
An archival flightline negative capturing a low-angle three-quarter perspective of the Spirit of St. Louis at Dutch Flats. The composition details the heavy-duty split-axle landing gear engineered by Donald A. Hall Sr. to withstand the 5,200-pound maximum overload takeoff weight. The fabric-doped aerodynamic wheel disc is clearly stenciled "Silvertown Airplane Cord", documenting the pneumatic tires provided by B.F. Goodrich. The view also highlights the engine exhaust stacks, Clark Y wing profile, and tail registration in the background.
Donald A. Hall Estate Collection
A 35mm documentary motion picture film still recording the principal leadership of the Ryan NYP project standing beside the fuselage of the Spirit of St. Louis at Dutch Flats, San Diego. Pictured from left to right: Aviator Charles A. Lindbergh in a dark suit, Ryan Airlines President B. F. Mahoney in a tweed three-piece suit and fedora, and Chief Engineer Donald A. Hall Sr. in a tailored dark suit with patterned tie, hands clasped behind his back. This image provides primary historical documentation of the three central figures responsible for creating the historic transatlantic aircraft.
Donald A. Hall Estate Collection
A rare 35mm documentary film still capturing the historic moment Charles A. Lindbergh and Chief Engineer Donald A. Hall Sr. shake hands in front of the Spirit of St. Louis at Dutch Flats. Charles Lindbergh on the left extends his hand with a broad smile, while Donald Hall leans forward to grip Lindbergh's hand warmly, flanked by B. F. Mahoney standing between them. Onlookers and Ryan mechanics watch the exchange from along the fuselage turtledeck, commemorating the successful completion of flight testing and mutual respect between pilot and aircraft designer.
Donald A. Hall Estate Collection
A primary historical action photograph recording the maiden flight trials of the Ryan NYP Spirit of St. Louis at Dutch Flats, San Diego, on April 28, 1927. Photographed from ground level directly ahead of the aircraft, the image captures Charles Lindbergh initiating taxi trials and takeoff ground acceleration across the unpaved dirt runway. Chief Engineer Donald A. Hall observed and logged these initial trials to confirm ground stability, rudder steering authority, and engine temperatures under operational ground roll conditions.
Donald A. Hall Estate Collection
An archival flight-test photograph capturing the Spirit of St. Louis airborne low over the dirt field of Dutch Flats during its maiden flight evaluations. Captured from a distance, the monoplane flies in ground effect just feet above the terrain with its landing gear clear of the runway, demonstrating immediate aerodynamic lift from Donald Hall's high-lift Clark Y wing profile. The background shows the dry scrub hills of San Diego surrounding the airfield.
Donald A. Hall Estate Collection
A dramatic action photograph recording the Spirit of St. Louis climbing rapidly into the cloudy sky during its first flight trials on April 28, 1927. Viewed from below as the aircraft banks away from Dutch Flats, the silhouette displays the 46-foot wingspan, streamlined struts, fixed landing gear, and empennage. Donald Hall monitored this initial 20-minute flight to verify initial rate of climb, control surface balance, and engine cooling.
Donald A. Hall Estate Collection
A panoramic documentary photograph showing the expanse of Dutch Flats during flight trials in late April or early May 1927. In the foreground, an airfield support plane and Ryan ground personnel stand on the dirt apron, while high in the center of the frame, the Spirit of St. Louis is captured flying in the circuit overhead. The horizon reveals an industrial smokestack emitting smoke, utility poles, and commercial waterfront buildings framing the historic San Diego airfield.
Donald A. Hall Estate Collection
An archival engineering action photograph capturing the Spirit of St. Louis flying at high speed at eye level across the dirt runway at Dutch Flats. Flying in level attitude just above the ground line, the image records Donald Hall and Charles Lindbergh conducting timed speed runs between measured ground markers to calibrate the cockpit pitot-static airspeed indicator prior to cross-country trials.
Donald A. Hall Estate CollectionResearch, permissions, and image requests
Contact the collection for credits, rights information, and permission to reproduce images.
